Grandad's Postbag 151211 FlySky CT6B transmitter
This is another Grandad's postbag episode. Spotted this FlySky transmitter cheap on eBay, probably old stock but at the price I thought it was worth having for the low level RC projects I do.
In reply to some comments there is no documentation in the box just a CD. As far as I can see you connect to a PC to program your settings and save it to a file on the PC. Then if you want different settings, you do it all again connected to the PC and save a different file. If you want to swap between settings as far as I can see you have to connect to your PC and swap files. Not very user friendly but for the sort of stuff I do I can live with that as a second transmitter to control a second boat or car when I need it like maybe the rescue boat. Here is a video on using the set-up system on the PC • Video I had a look at the software and as I suspected you make all the changes you want and save a file on you computer. At the same time it saves it on the transmitter. If you want to change anything you have to plug it back into the computer. Even simple things like reversing the directions for a channel can only be done connected to the computer. I think the 4 model thing it is talking about is that the software package allows you to choose from 4 different types of setup - plane (which is calls ACRO) and then 3 types of helicopter. One thing I do want to try is mixing the elevator and rudder channels, I haven't tried it yet but it looks like it should be able to do it. I have a small receiver with onboard servos that I want to try that with.
Here are the eBay listing I used. I am not endorsing these products I am just answering the questions people have asked. I suggest you do your own search as prices and specifications will vary.
FLY SKY 2.4G FS-CT6B 6 CH CHANNEL RADIO MODEL RC TRANSMITTER RECEIVER CONTROL http://www.ebay.co.uk/itm/191740963226
Features:
Super active and passive anti-jamming capabilities.
Very low power consumption.
High receiving sensitivity.
8 model memory, digital control.
Can be programmed by PC with included software.
Full range 2.4GHz 6-channel radio.
4-Model Memory.
4 Type (Airplane, Heli90, Heli120, Heli140).
Integrated timer.
Contrast Adjustment.
Throttle cut.
Computer Programmable.
USB Socket.
Use a linear spread of fine paragraph by exces antenna.
It covers the entire band width of he antenna bandwidth range.
High quality and stability.
Specifications:
Transmitter/Receiver: 2.4GHz
Model Name:6 channels transmitters
Model No:FS-CT6B
Channels:6 channels
Mode Type:Airplane, Helicopter,Glider
Stick Mode:Left hand or Right hand
Modulation:Frequency Modulation
Antenna length:115cm/26mm
Code Type:PPM/GFSK
Power:12 VDC
RF Power: Less than 0.8W
Color: Black + Blue
Package Size
Filmed using FujiFilm FinePix S4800
Edited using Serif MoviePlus Starter Edition
Low Pass Filter 6500 hz
If you want help setting up your FS-CT6B I recommend this video by HobbyPartz • Video and follow their link in their video description to get the CT6B config software if you don't have the disk.
Here is a YouTube search that will find videos on the subject https://www.youtube.com/results?searc...
Richard Harris suggested this software as an alternative to the FlySky software for setting up your transmitter
http://www.sgr.info/usbradio/
• Part 2: T6Config Tutorial for RC Airplanes...
also useful
