QUESTION -01
a.
You are required to set up the above network (Fig. 1) for the Computer Engineering Department (assume a building with three floors, E-Ethernet switches, R-Routers). The network is to be used by both staff and
students as shown. All types of communication such as lecturer-lecturer, lecturer-student, and student-student should be possible in the network without any restrictions based on physical locations (floors). However, when communicating, there should be sufficient traffic isolation for the staff and students (traffic from staff should not unnecessarily reach students and vice versa). Use the10.0.0.0/8 address block for the whole department and the address 142.3.2.0/24 for the external link attached to R1. Accordingly, assign (mark) appropriate IP addresses for the devices/interfaces and identify VLANs needed, and NAT. Set up and configure the network. Set up web servers on Server1 and Server2. (some Cisco L3 switch models: 3550, 3750,3560, 4500, 6500, 7000, etc.).
b.
Test & verify the network:
-Access theweb server on Server2 from PC1 (Student).
-Access the webserver on Server2 from PC2 (Lecturer).
-Accessing the webserver on Server1 from Server2.
-Ping/traceroute from PC1 to Server2.
-Ping/traceroute from Server2 to Server1.
