MS SQL Server 2022 DBA Real Time Home Lab

Опубликовано: 16 Апрель 2023
на канале: MS SQL DBA Tech Support
2,454
29

How to Build SQL Server 2022 DBA Real Time Home Lab
in VMware workstation
Hardware Minimum Requirements:
Virtualization support in Bios
8 GB RAM
2.5 GH processor or more
500 HDD or 1TB HDD | SSD would be faster.
Other Requirements:
64 Bit OS (windows 7/8/10)
VMware workstation or hyper v or Virtual Box
Windows SQL Server 2022
Windows Server 2022

My environment:
32 GB Ram
1 TB SSD and 1 TB HDD
Intel with 4 physical cores with virtualization support (4x2=8Cores)
Windows 10 64 bit os
Vmware workstation 17 Pro

Basics steps we need to check For Error Free installation
1. All Member servers should be part of the Domain
2. Firewall should be off
3. Check communication between and Domain and member servers
4. Check Nslookup for all servers (it means DNS is resolving hostname to IP and vice versa)
5. Login with Domain administrator or user which is having Domain Level Permissions every where

Step By step:
1. Enable Virtualization (VT) In BIOS
2. Install VMware workstation
3. Install 3 Windows Server OS
4. Install VMware Tools [Environment Specific]
5. Disable IPv6 and configure IPs as shown in the demo environment Picture
6. Install Extra network adapter for node 2 & node 3 for heartbeat
7. Install Active Directory and configure Forward Lookup and Reverse Lookup Zones in Domain OS.
8. Disable the password complexity policy in domain
9. Disable the public, Private and domain firewalls rules in domain os.
10. Disable the public and private firewall rules in node 2 and node 3
11. Join the Node 1 and node 2 to domain.
12. Disable the domain firewall rule in node 2 and node3
13. Install .Net 3.5 Framework in Node 1 & Node 2
14. Install ISCSI Target Server and create Virtual Hard disks in domain and Assign to Node 1 & Node 2
15. Connect to ISCSI Target through ISCSI Initiator and Assign Drive Letters (Note: Drive Letters Should and names should be same In Node 1 & Node 2)
16. Install Fail-over clustering Feature in Node 1 & Node 2
17. Install Fail-over Cluster Automation Server Feature in Node 1 &
Node 2
18. Install ssms in node1 and node2
19. Install Standalone SQL Server 2022 with sql2022hyd01 in node1
20. Install Standalone SQL Server 2022 with sql2022hyd02 in node2
21. Enable Always on feature On Both Standalone Instances in Node 1 & Node 2 and configure always on
22. Create and Validate Cluster
23. Install SQL failover cluster in node1 with (sql202201)
24. Install SQL Server With add a node to cluster Option in Node2 {Note: This works as Active - Passive SQL Cluster}
25. Install SQL failover cluster in node1 with (sql202202)
26. Install SQL Server With add a node to cluster Option in Node2 {Note: This works as Active - Active SQL Cluster}
27. Restore Any Sample Databases like Adventure works for Replication Practical
28. Configure Log shipping, Mirroring & Transactional Replication
