Simulation of temperature distribution in water-cooled induction heating coil - Comsol Multiphysics
This model shows how an induction heating coil can be kept cold by making water flow through it. The coil is supplied with a continuous sinusoidal current input and it heats up due to Joule heating (resistive heating). The steady-state temperature distribution of the coil is obtained. Preventing the coil from heating up is important for safety. The simulation uses 3 physics interfaces (magnetic fields, laminar flow, heat transfer). The tutorial also shows how a solution from one study can be used in another separate study using the "withsol" operator.
00:00 Intro
01:40 geometry
04:55 Selections
06:50 Materials
09:30 Physics, magnetic fields
11:15 Physics, laminar flow
12:55 Physics, heat transfer
15:55 Mesh
19:25 Frequency domain study
22:50 Heat source, using withsol
25:13 Stationary study
28:15 Results
